TECHNICAL SPECIFICATIONS
GTIN / EAN 4045759054177
item number 12100566
fastener KMR nails type nail strips K20 °
Diameter min 2.8 mm
Diameter max 3.8 mm
Length min 50 mm
Length max 100 mm
Dimensions L / H 369/529 mm
mass 3.6 kg
safety yoke Contact actuation
Permissible air pressure 8.0 bar / 0.8 Mpa
Recommended operating pressure 6.0-8.0 bar / 0.60-0.80 Mpa
Air consumption per input operation 3.1 liters at 6 bar (0.6 MPa)
A-weighted single-event sound power level L Wa, 1s = 104.3 dB (A)
A-weighted single event emissions Sound pressure level at the workplace L pA, 1 s = 98.1 dB (A)
