TECHNICAL SPECIFICATIONS
GTIN / EAN 4045759054184
item number 12100567
fastener KMR nails type nail strips P34 ° D head / KMR nails type nail strips K34 °
Diameter min 2.8 mm
Diameter max 3.4 mm
Length min 64 mm
Length max 100 mm
Dimensions L / H 353/369 mm
mass 3.6 kg
safety yoke Contact actuation
Permissible air pressure 8.0 bar / 0.8 Mpa
Recommended operating pressure 6.0-8.0 bar / 0.60-0.80 Mpa
Air consumption per input operation 2.9 liters at 6 bar (0.6 MPa)
A-weighted single-event sound power level L Wa, 1s = 103 dB (A)
A-weighted single event emissions Sound pressure level at the workplace L pA, 1s = 94 dB (A)
