KMR 3503 20° Timber & Joinery Angled Air Framing Strip Nailer – 90-130mm

KMR 3503 20° Timber & Joinery Angled Air Framing Strip Nailer – 90-130mm

£595.00

£595.00

KMR 3503 20° Timber & Joinery Angled Air Framing Strip Nailer – 90-130mm

Features
Handy
Ergonomic
Depth adjustment
Additional handle

Applications
Timber makers
Carpentry
Roofers
Cladding
Formwork
Frame construction

Contents
Spare parts list
Service instructions
Safety glasses
Allen key
Additional handle
Oil bottle

TECHNICAL SPECIFICATIONS
GTIN / EAN 4045759058342
item number 12100624
fastener KMR nails type nail strips K20 °
Diameter min 3.8 mm
Diameter max 4.2 mm
Length min 90 mm
Length max 130 mm
Dimensions L / H / B 553/478/144 mm
mass 6.2 kg
safety yoke Single Shot
Permissible air pressure 8.0 bar / 0.8 Mpa
Recommended operating pressure 5.0-8.0 bar / 0.50-0.80 Mpa
Air consumption per input operation 4.3 liters at 6 bar (0.6 MPa)
A-weighted single-event sound power level L Wa, 1s = 100.5 dB (A)
A-weighted single event emissions Sound pressure level at the workplace L pA, 1 s = 96.4 dB (A)
